Ganfeng 3.2V 100Ah LiFePO₄ Battery Cell

Description

Premium Grade Lithium Iron Phosphate (LiFePO₄) Prismatic Cell

The Ganfeng 3.2V 100Ah LiFePO₄ battery cell is a high-performance prismatic cell designed for reliable and long-lasting energy storage applications. With excellent safety, high power capability and long service life, it is ideal for ESS, solar storage, UPS systems, EVs and industrial battery packs.

Key Specifications

Specification| Details
Brand| Ganfeng LiEnergy
Model| 48173125-100Ah
Cell Type| LiFePO₄ (LFP) Prismatic
Nominal Voltage| 3.2V
Rated Capacity| 100Ah
Energy| 320Wh
Standard Charge Current| 50A (0.5C)
Maximum Continuous Charge| 100A (1C)
Maximum Charge Voltage| 3.65V
Standard Discharge Current| 50A (0.5C)
Maximum Continuous Discharge| 100A (1C)
Cycle Life| 8000+ Cycles
Warranty| 5 Years
Cell Weight| Approx. 2.15kg
Dimensions| 174.2 × 132.3 × 47.8mm
Chemistry| Lithium Iron Phosphate (LiFePO₄)

Main Features

– 8000+ cycle long service life
– 5-Year Warranty
– High energy density and excellent stability
– High continuous charge/discharge capability
– Excellent thermal and chemical stability
– Maintenance-free operation
– Suitable for high-capacity battery packs
– Ideal for solar and energy storage applications

Recommended Applications

– Solar Energy Storage Systems (ESS)
– Home & Commercial Energy Storage
– UPS & Backup Power Systems
– Off-Grid Solar Systems
– Telecom Backup Systems
– Electric Vehicles (EV)
– Electric Bikes & Scooters
– Industrial Battery Packs
– 12V, 24V and 48V/51.2V LiFePO₄ Battery Systems

Common Battery Configurations

4S: 12.8V 100Ah — 1.28kWh
8S: 25.6V 100Ah — 2.56kWh
16S: 51.2V 100Ah — 5.12kWh

ChargeX Quality

At ChargeX, these high-quality Ganfeng LiFePO₄ cells can be professionally assembled with a suitable BMS, busbars and protection system to build reliable battery solutions for residential, commercial and industrial energy storage.
