TDT 4S 100A LiFePO₄ BMS

Description

High-Performance Battery Management System for 4S LiFePO₄ Batteries
Key Specifications
Brand: TDT Electronics
BMS Type: Smart LiFePO₄ BMS
Battery Chemistry: LiFePO₄ (LFP)
Battery Configuration: 4S
Nominal Battery Voltage: 12.8V
Maximum Charge Voltage: 14.6V
Continuous Charge Current: 100A
Continuous Discharge Current: 100A
Balance Current: 1A Active Balance
Communication: UART
Temperature Sensor: NTC
Heating Function: Supported
Switch Control: Supported
Cell Voltage Monitoring: Individual cell monitoring
Protection: Overcharge, over-discharge, over-current, short-circuit and temperature protection
Application: LiFePO₄ Battery Packs, Solar Storage, UPS, Inverters, RV, Marine & Energy Storage Systems
Features
100A High-Current Protection
1A Active Cell Balancing
Smart Monitoring & Communication
NTC Temperature Protection
Heating Interface
Compact & Heavy-Duty Design
Suitable for 12.8V LiFePO₄ battery systems
